Plastic Sheet Welder RPH3000
- Model
- RPH3000
Item specifics
- Maximum Welding Width
- 3000 mm
- Maximum Welding Thickness
- 30 mm
- Standard Applied
- DVS2207
- Weldable Materials
- PE, PP, PVDF, PVC, ABS etc
- Welding Type
- Plastic Sheet Butt Welding
- Certificate
- CE
Review
Description
Detail Information
Plastic Sheet Welder RPH3000 Introduction
The Weissenberg RPH3000 is a high-capacity butt welding machine designed for joining thermoplastic sheets from 3 to 30 mm in thickness, with a maximum welding width of 3000 mm. Engineered for demanding industrial environments such as aquaculture, PP scrubber tower fabrication, and water treatment plants, it ensures reliable performance even on large-format sheets.
Plastic Sheet Welder RPH3000 Features
Plastic Sheet Welder RPH3000 Technical Parameters
| Product model | RPH3000 |
| Maximum Working width | 3,000mm |
Machine Length | 4,750mm |
Machine width | 2,300mm |
Machine height | 1,200mm |
PE (0.15 N/mm²) | 3-30 |
PP (0.10 N/mm²) | 3-30 |
| PVDF (0.10 N/mm²) | 3-30 |
| Power supply | 230/400V 3/N/PE,50/60 Hz |
| Power consumption | 5.5KW |
Compressed Air Connection | 4-8bar |
Max. HeatingTemperature | 260°C |
| Optional Auxiliary Tools | 90° degree angle device Rolling auxiliary device |
* Parameters are measured under standard operating conditions and may vary in actual use.
* If you notice any issues or need help adjusting the parameters, feel free to contact us.
* If you notice any issues or need help adjusting the parameters, feel free to contact us.
File Downloads
For more product related parameter files, please contact us.
