Plastic Sheet Welder RPH2000
- Model
- RPH2000
Item specifics
- Maximum Welding Width
- 2000 mm
- Maximum Welding Thickness
- 20 mm
- Standard Applied
- DVS2207
- Weldable Materials
- PE, PP, PVDF, PVC, ABS etc
- Welding Type
- Plastic Sheet Butt Welding
- Certificate
- CE
Review
Description
Detail Information
Plastic Sheet Welder RPH2000 Introduction
The Weissenberg RPH2000 offers powerful and efficient welding for thermoplastic sheets between 3 and 20 mm thick, capable of welding sheets up to 2000 mm in length. Built for industrial use, it excels in fabricating tanks, chemical reservoirs, pipelines, ventilation, and water treatment systems. With ±5°C heating plate control and compliance with DVS 2207 standards, it ensures consistent, high-quality welds for critical applications.
Plastic Sheet Welder RPH2000 Features
Plastic Sheet Welder RPH2000 Technical Parameters
| Product model | RPH2000 |
| Maximum Working width | 2,000mm |
Machine Length | 3,050mm |
Machine width | 2,000mm |
Machine height | 1,200mm |
PE (0.15 N/mm²) | 3-20 |
PP (0.10 N/mm²) | 3-20 |
| PVDF (0.10 N/mm²) | 3-20 |
| Power supply | 230/400V 3/N/PE,50/60 Hz |
| Power consumption | 3.5KW |
Compressed Air Connection | 4-8bar |
Max. HeatingTemperature | 260°C |
| Optional Auxiliary Tools | 90° degree angle device Rolling auxiliary device |
* Parameters are measured under standard operating conditions and may vary in actual use.
* If you notice any issues or need help adjusting the parameters, feel free to contact us.
* If you notice any issues or need help adjusting the parameters, feel free to contact us.
File Downloads
For more product related parameter files, please contact us.
