Plastic Sheet Welding& Bending Machine RPZ6000
- Model
- RPZ6000
Item specifics
- Maximum Working Width
- 6000 mm
- Welding Thickness
- 3-30 mm
- Bending Thickness
- 2-20 mm
- Bending Angle:
- 0-95°
- Standard Applied
- DVS2207
- Weldable Materials
- PE, PP, PVDF, PVC, ABS etc
- Certificate
- CE
Review
Description
Detail Information
Plastic Sheet Welding&Bending Machine RPZ6000 Introduction
RPZ6000 is a heavy-duty machine designed for extra-large plastic fabrication, supporting plastic sheet widths up to 6000mm. Equipped with Mitsubishi PLC control and high-quality SMC pneumatic components, the RPZ6000 guarantees smooth operation, strong weld strength, and consistent, reliable performance for demanding industrial applications.
Plastic Sheet Welding&Bending Machine RPZ6000 Features
Plastic Sheet Welding&Bending Machine RPZ5000 Technical Parameters
| Product model | RPZ6000 |
| Maximum Working width | 6,000mm |
Machine Length | 7,750mm |
Machine width | 3,100mm |
Machine height | 1,220mm |
Welding Thickness | 3-30mm |
Bending Thickness | 3-20mm |
Bending Angle | 0-95° |
| Power supply | 230/400V 3/N/PE,50/60 Hz |
| Power consumption | 11+10*2 KW |
Compressed Air Connection | 4-8bar |
Max. HeatingTemperature | 260°C |
* Parameters are measured under standard operating conditions and may vary in actual use.
* If you notice any issues or need help adjusting the parameters, feel free to contact us.
* If you notice any issues or need help adjusting the parameters, feel free to contact us.
