Feasibility Analysis of Splicing PE and PP of the Same Thickness with a Plastic Sheet Welding Machine

Plastic welding is a widely used joining technology in the manufacturing industry. Polyethylene (PE) and polypropylene (PP), as two of the most common plastic materials, have always drawn attention for their welding performance. This article explores the feasibility, technical challenges, and solutions for splicing PE and PP plates of the same thickness using a plastic plate welding machine.

Comparison of Material Properties Between PE and PP

Although polyethylene (PE) and polypropylene (PP) both belong to the polyolefin family, their chemical structures and physical properties exhibit significant differences:

• Chemical Structure: PE is polymerized from ethylene monomers, while PP is polymerized from propylene monomers, with methyl side groups on the PP molecular chain.
• Melting Point: The melting point of PE is approximately 130°C–140°C, while that of PP is about 160°C–170°C.
• Surface Energy: PP has slightly higher surface energy than PE, which affects interfacial bonding during welding.
• Crystallinity: PP generally has higher crystallinity than PE, influencing molecular diffusion during welding.

These differences pose challenges for the direct welding of PE and PP, particularly in applications requiring high-strength joints.

Working Principles of Plastic Plate Welding Machines

Plastic plate welding machines typically employ the following processes:

1. Hot Plate Welding: The plastic surface is melted using a heated plate, followed by pressurized joining.
2. Ultrasonic Welding: High-frequency vibrations generate heat to melt the plastic.
3. Hot Gas Welding: A hot air gun heats the plastic surface, and a welding rod is used as filler material.
4. Extrusion Welding: Molten plastic is extruded as an intermediate layer to join the two parts.

For welding dissimilar materials like PE and PP, hot plate welding and extrusion welding may be the more suitable options.

Technical Challenges in Welding PE and PP of the Same Thickness

Welding polyethylene (PE) and polypropylene (PP) plates of the same thickness presents several major challenges:

1. Melting Point Difference: PP has a melting point approximately 30°C–50°C higher than PE, requiring precise temperature control.
2. Incompatibility: PE and PP cannot form a molecular-level mixture in their molten states.
3. Differential Shrinkage Rates: Different shrinkage rates during cooling may lead to warping or stress concentration.
4. Interfacial Strength: Due to the lack of molecular diffusion, the weld interface strength is typically lower than that of welding the same materials.

Possible Solutions

Despite these challenges, the following methods can improve the success rate of PE and PP welding:

1. Use of Compatibilizers: Adding compatibilizers such as PP-g-MAH (maleic anhydride grafted polypropylene) can enhance interfacial bonding.
2. Intermediate Layer Materials: Employing ethylene-propylene copolymers as an intermediate layer can strengthen the joint.
3. Surface Treatment: Corona treatment or flame treatment can increase surface energy and improve weldability.
4. Optimized Welding Parameters: Precise control of temperature, pressure, and time parameters to accommodate the different requirements of both materials.
5. Mechanical Interlocking Design: Incorporating interlocking structures (e.g., grooves or protrusions) at the weld interface to enhance mechanical bonding strength.

Different Melting Points of PP and PE

Polypropylene (PP) and polyethylene (PE), as the two most common polyolefin plastics, exhibit significant differences in their melting points:

1. Melting Range of Polyethylene (PE):
   • LDPE (Low-Density Polyethylene): 105–115°C
   • LLDPE (Linear Low-Density Polyethylene): 120–125°C
   • HDPE (High-Density Polyethylene): 130–137°C
   • UHMWPE (Ultra-High Molecular Weight Polyethylene): 130–138°C
2. Melting Range of Polypropylene (PP):
   • Homopolymer PP: 160–165°C
   • Random Copolymer PP: 145–155°C
   • Block Copolymer PP: 160–170°C

Can Weissenberg's Plastic Sheet Welding Machine be used for welding PP and PE?

Below is a comprehensive analysis of whether same-thickness PE and PP sheets can be joined using Weissenberg’s Plastic Sheet Welding Machine, summarizing key material differences, the machine’s capabilities, technical challenges, and practical solutions.

Summary

Weissenberg’s Plastic Sheet Welding Machines support both PE and PP materials via heating plate and extrusion welding modes, offering precise temperature and pressure control for butt welding, 90° corner welding, and rolling welding. Despite the 20–50 °C difference in melting points between PE (115–135 °C) and PP (130–171 °C), and their inherent immiscibility, successful joints are achievable by optimizing parameters, using compatible filler rods (e.g., PP-g-MAH), applying surface treatments (flame or plasma), and, if needed, inserting an intermediate copolymer layer. With proper quality control, Weissenberg machines can produce reliable PE-to-PP welds suitable for non-critical structural applications.

Welding Technologies in Weissenberg Plastic Sheet Welding Machines

Weissenberg offers multiple welding modes in one platform, including butt welding machine for plastic sheet, extrusion welder.

Hot-Plate (Butt) Welding: Heat­-conductive platens melt sheet faces, then parts are pressed together under controlled pressure. Ideal for PP, which resists ultrasonic welding

Extrusion Welding: A heated plastic rod is extruded into the joint, fusing base sheets. Requires compatible filler rod (same polymer) for strength

90° Corner & Rolling Welding: Specialized fixtures allow vertical and curved seams in one setup

Machine Capabilities

• Supports PE, PP, PVC, PVDF, HDPE sheets (3–60 mm thickness) with CNC-controlled temperature (up to ~300 °C) and pressure settings
• Handheld EX2/EX3 extrusion welders deliver up to 2.5 kg/h rod feed for on-site repairs on PE and PP

Feasibility of Welding PE to PP Sheets

Technical Challenges

Melting-Point Mismatch (ΔT ≈ 20–50 °C): Requires precise temperature control to fully melt PE without degrading PP or vice versa

Immiscibility: PE and PP cannot interdiffuse at the molecular level; joints rely on mechanical mixing or compatibilizers

Shrinkage Differences: Differential cooling rates induce residual stresses and potential warpage

Low Surface Energy: Hinders wetting; untreated surfaces yield weak adhesion

Solutions & Process Optimizations

• Compatibilizers: Incorporate 2–5 wt% PP-g-MAH (maleic-anhydride-grafted PP) into filler rod or intermediate layer to promote interfacial adhesion; optimal around 3 wt% for recycled PP/PE blends, improving tensile strength by >30%

Intermediate Copolymer Layer: Use ethylene-propylene copolymer (EPC) or PE-g-iPP grafts (triblock/polystyrene copolymers) as a thin interlayer to bridge the two polymers

Surface Activation:

Flame Treatment: Increases total surface energy of PE from ~28.7 to 56.3 mN/m and of PP from 29.7 to 44.6 mN/m, boosting peel strength by up to 700% for PE and 68% for PP

Corona/Plasma: Low-temperature plasma can achieve similar or higher polar surface energy increases with better uniformity

Parameter Optimization:

Temperature Ramp: Preheat both sheets to a mid-range (~150–155 °C) to soften PE and partially melt PP.

Pressure & Dwell: Apply 0.4–0.8 MPa for 20–30 s melt phase, followed by a seal phase of 5–10 s under reduced pressure to consolidate the joint

Melt-Zero Calibration: Ensure full contact (“melt-zero”) across the entire weld rib to avoid cold spots

Mechanical Interlock (Optional): Design a shallow tongue-and-groove or serrated profile along the joint to add shear strength (principles from overmolding interlocks)

Practical Guidelines on Weissenberg Plastic Sheet Welder

Machine Setup: Select butt-welding mode on RPH Series; set platen to 160 °C, extruder to 190 °C for PP rod feed

Surface Prep: Flame-treat both sheet faces (0.5 m/s flame speed, 3 mm standoff) immediately before welding.

Filler Rod Selection: Use PP-g-MAH rod for extrusion welding; feed at 2 kg/h to ensure even bead formation.

Welding Sequence:

Pre-clamp & Align sheets in pneumatic locking clamps.

Heating Phase: Engage hot plate for 20s at least

Forge Phase: Retract plate, press sheets together

Cooling Phase: Maintain pressure for requested time during to standard DVS2207-11

Quality Control: Perform bend or tensile tests per DVS 2207 standards to verify ≥60% of same-material weld strength

Conclusion

By leveraging Weissenberg’s versatile welding modes, precise CNC-controlled parameters, and incorporating compatibilization and surface-activation strategies, welding same-thickness PE to PP sheets is technically feasible for many industrial applications. While joint strength will remain below that of homogeneous welds (typically ~60–80% of base material strength), careful process design and quality testing ensure reliable performance in non-critical structures such as packaging liners, chemical tank linings, and decorative panels. As material science advances (e.g., novel graft copolymers), the PE/PP joint performance on Weissenberg equipment will continue to improve.
